GJYXCH GJYXFCH fibra optica manufacturer G657A ftth drop cable 1 2 4 core outdoor fiber optic cable ftth

EMAIL



 Fiber Parameters

No.

Items

Unit

Specification

G.652D

1

Mode Field Diameter

1310nm

μm

9.2±0.4

1550nm

μm

10.4±0.5

2

Cladding Diameter

μm

124.8±0.7

3

Cladding Non-Circularity

%

≤0.7

4

Core-Cladding Concentricity Error

μm

≤0.5

5

Coating Diameter

μm

245±5

6

Coating Non-Circularity

%

≤6.0

7

Cladding-Coating Concentricity Error

μm

≤12.0

8

Cable Cutoff Wavelength

nm

λcc≤1260

9

Attenuation(max.)

1310nm

dB/km

≤0.4

1550nm

dB/km

≤0.3



 Cable Parameters

 Items

 Specifications

 Fiber Count

4

Colored Coating Fiber

 Dimension

250±15μm

 Color

Blue,Orange,Green,Brown

Strength Member

 Dimension

0.45mm

 Material

Steel

Self-Supporting Member

 Dimension

1.0mm

Material

 Steel

Jacket

 Dimension

5.2±0.2mm×2.0±0.1mm

 Material

LZSH

 Color

Black,White,Customizable





 Mechanical and Environmental Characteristics

 Items

 Unite

 Specifications

 Tension(Long Term)

N

300

 Tension(Short Term)

N

600

 Crush(Long Term)

N/10cm

1000

 Crush(Short Term)

N/10cm

2200

 Min. Bend Radius(Dynamic)

mm

20D

 Min. Bend Radius(Static)

mm

10D

 Installation Temperature

-20~+60

 Operating Temperature

-40~+70

 Storage Temperature

-40~+70



Advantage:

·         Using special low-bend-sensitivity fiber B6 (G.657), provides greater bandwidth and excellent communication transmission property

·         Two parallel strength members (metal or FRP) ensure the fiber are better protected

·         Low smoke zero halogen flame-retardant jacket leads to more safety and environmental protection

·         Simple structure, lightweight and practicability

·         Novel flute design, easily strip and splice, simplify the installation and maintenance

·         Additional metal hanging wire can enhance the tensile strength
